Uhf Socket Adaptor

Uhf Socket Adaptor Specification

Material
Brass with Nickel Plating

Application
Radio communication, amateur radio, RF systems

Connector Type
UHF

Capacity
Up to 500V RMS

Voltage Rating
500V RMS

Connector
UHF Socket Adaptor

Pairs
Single pair (one male, one female)

Cable Type
Coaxial

Sheild
Metal shielding for enhanced RF immunity

Insulation
PTFE

Outer Diameter
~16 mm

Length
Adapter body approx. 32 mm

Number of Conductor
1

Uhf Socket Adaptor Trade Information

Minimum Order Quantity
1000 Pieces

Delivery Time
2 Week

Sample Available
Yes

Sample Policy
Contact us for information regarding our sample policy

Packaging Details
Standard

Main Domestic Market
All India

About Uhf Socket Adaptor

The Uhf Socket Adaptor is a name for a threaded RF connector. The connector design was invented in the 1930s for use in the radio industry, and is a shielded form of the "banana plug". It is a widely used standard connector for HF transmission lines on full-sized radio equipment. UHF adapters are external connectors that connect different plugs and sockets and help to adapt existing cables to a new plug and socket configuration. Uhf Socket Adaptor is made available by us for industrial uses.

Highly Durable and Secure Connection

Built to exceed 1000 mating cycles, this UHF Socket Adaptor provides a consistent, low-loss electrical interface thanks to its robust brass core and nickel-plated finish. Its precision inline mounting allows for secure integration into both new and retrofit systems, ensuring reliability in demanding environments.

Optimized for High-Frequency Performance

Operating efficiently from DC up to 300 MHz, the adaptor maintains low signal loss (<0.2 dB at 100 MHz) with enhanced metal shielding that minimizes RF interference. The use of PTFE insulation and careful construction supports clear signal transmission, making it suitable for critical RF and radio communication applications.

FAQs of Uhf Socket Adaptor:

Q: How is the UHF Socket Adaptor installed in an RF system?

A: The UHF Socket Adaptor features an inline mounting style, enabling quick and straightforward connection between coaxial cables and RF equipment. You simply connect one male and one female pair and secure them to ensure stable signal transmission.

Q: What are the main benefits of the nickel-plated brass construction?

A: Nickel plating over brass provides excellent durability, corrosion resistance, and reliable conductivity, maintaining stable connections through more than 1000 mating cycles, even in challenging environments.

Q: When should I consider using this UHF Socket Adaptor?

A: This adaptor is ideal for applications where a 50 Ohm impedance and frequency range from DC to 300 MHz are requiredsuch as in radio communication, amateur radio setups, and specialized RF systems.

Q: Where is this product manufactured and supplied from?

A: The UHF Socket Adaptor is designed, manufactured, and exported from India, serving global needs for high-quality RF connectors and adaptors.

Q: What measures ensure minimal signal loss in this adaptor?

A: A combination of metal shielding, PTFE insulation, and precise engineering ensures insertion loss remains below 0.2 dB at 100 MHz, providing optimal signal integrity for sensitive RF applications.

Q: How does RoHS compliance benefit users?

A: RoHS compliance guarantees that the adaptor is free from hazardous substances, making it safer for both users and the environment, and meeting international regulatory requirements.

Q: What types of cables and connectors are compatible with this adaptor?

A: This adaptor is specifically designed to work with 50 Ohm coaxial cables and UHF connector types, supporting a single conductor configuration for various RF and radio communication applications.
